| 1 |
101-945 |
Complete Engine Assembly (224cc)
|
USD$208.74
|
|
|
101-945 |
| 2 |
101-946 |
Base
|
USD$55.55
|
|
|
101-946 |
| 3 |
101-947 |
Inner Casing (Left )
|
USD$31.67
|
|
|
101-947 |
| 4 |
101-948 |
Inner Casing (Right)
|
USD$29.59
|
|
|
101-948 |
| 5 |
101-949 |
Casing (Left, Light Grey)
|
USD$26.27
|
|
|
101-949 |
| 6 |
101-950 |
Casing (Right, Light Grey)
|
USD$22.69
|
|
|
101-950 |
| 7 |
101-951 |
Top Panel
|
USD$13.61
|
|
|
101-951 |
| 8 |
101-952 |
Engine Oil Maintenance Cover
|
USD$7.84
|
|
|
101-952 |
| 9 |
101-953 |
Rear Cover
|
USD$33.98
|
|
|
101-953 |
| 10 |
101-954 |
Casing (Front)
|
USD$14.94
|
|
|
101-954 |
| 11 |
101-955 |
Control Panel Housing
|
USD$16.09
|
|
|
101-955 |
| 12 |
101-956 |
Top Cover, Fuel Tank
|
USD$15.20
|
|
|
101-956 |
| 13 |
101-957 |
Front Handle Cover
|
USD$5.84
|
|
|
101-957 |
| 14 |
101-958 |
Raer Handle Cover (Top)
|
USD$7.03
|
|
|
101-958 |
| 15 |
101-959 |
Rear Handle Cover (Bottom)
|
USD$7.03
|
|
|
101-959 |
| 16 |
900-175 |
Bolt, Flange M6x20 (Zn)
|
USD$2.07
|
|
|
900-175 |
| 17 |
101-960 |
Ignition Bushing
|
USD$2.25
|
|
|
101-960 |
| 18 |
101-961 |
Inverter Bracket
|
USD$11.27
|
|
|
101-961 |
| 19 |
101-962 |
Front Frame Post (Left)
|
USD$15.46
|
|
|
101-962 |
| 20 |
101-963 |
Front Frame Post (Right)
|
USD$17.28
|
|
|
101-963 |
| 21 |
101-964 |
Fuel Tank Bracket (front)
|
USD$9.02
|
|
|
101-964 |
| 22 |
101-965 |
Fuel Tank Bracket (rear)
|
USD$6.64
|
|
|
101-965 |
| 23 |
101-966 |
Front Handlebar Bracket
|
USD$12.48
|
|
|
101-966 |
| 24 |
101-967 |
Rear Handlebar Bracket
|
USD$12.99
|
|
|
101-967 |
| 25 |
101-968 |
Rear Frame Post (Left)
|
USD$12.99
|
|
|
101-968 |
| 26 |
101-969 |
Rear Frame Post (Right)
|
USD$12.99
|
|
|
101-969 |
| 27 |
101-970 |
Fuel Tank Bracket (Right)
|
USD$8.05
|
|
|
101-970 |
| 28 |
101-971 |
Battery Holding Bracket
|
USD$9.97
|
|
|
101-971 |
| 29 |
101-972 |
Knob Plug
|
USD$2.78
|
|
|
101-972 |
| 30 |
101-973 |
Rope Guide, Recoil Starter
|
USD$4.43
|
|
|
101-973 |
| 31 |
101-974 |
Fuel Hose (Canister & Air Filter)
|
USD$3.11
|
|
|
101-974 |
| 32 |
900-098 |
Flat Washer 12x4x1mm (Zn)
|
USD$2.15
|
|
|
900-098 |
| 33 |
101-976 |
Li-ion Battery (12V/2.0Ah)
|
USD$48.42
|
|
|
101-976 |
| 34 |
101-977 |
Battery Terminal Block
|
USD$19.02
|
|
|
101-977 |
| 35 |
101-978 |
Frame Cover, Recoil Handle
|
USD$5.72
|
|
|
101-978 |
| 36 |
101-979 |
Fuel Deflector
|
USD$9.53
|
|
|
101-979 |
| 37 |
101-980 |
Muffler Housing Gasket
|
USD$19.34
|
|
|
101-980 |
| 38 |
101-981 |
Wheel Axle
|
USD$16.15
|
|
|
101-981 |
| 39 |
101-982 |
Fuel Tank
|
USD$51.31
|
|
|
101-982 |
| 40 |
101-983 |
Remote Receiver Onboard Module
|
USD$45.49
|
|
|
101-983 |
| 41 |
101-984 |
Li-ion Battery Voltage Regulator
|
USD$21.28
|
|
|
101-984 |
| 42 |
102-163 |
Fuel Hose 4x10/6x12-L95mm
|
USD$7.79
|
|
|
102-163 |
| 43 |
102-164 |
Fuel Hose 4x10/6x12-L55mm
|
USD$5.49
|
|
|
102-164 |
| 44 |
900-114 |
Flat Washer 24x15x1mm (BLK)
|
USD$2.95
|
|
|
900-114 |
| 45 |
900-137 |
Bolt, Flange M6x16 (BLK)
|
USD$2.18
|
|
|
900-137 |
| 46 |
101-988 |
Canister Bracket
|
USD$4.43
|
|
|
101-988 |
| 47 |
101-989 |
Anti Vibration Rubber Foot
|
USD$12.95
|
|
|
101-989 |
| 48 |
101-990 |
DC Voltage Regulator (Li-ion Battery version)
|
USD$28.46
|
|
|
101-990 |
| 49 |
101-991 |
Fuel Selector
|
USD$4.94
|
|
|
101-991 |
| 50 |
900-068 |
Spring Nut ST6.0x19mm (Zn)
|
USD$3.24
|
|
|
900-068 |
| 51 |
101-992 |
Engine Oil Plug
|
USD$2.78
|
|
|
101-992 |
| 52 |
101-993 |
Fuel Cap
|
USD$9.78
|
|
|
101-993 |
| 53 |
101-994 |
Rivet 3x15mm
|
USD$2.25
|
|
|
101-994 |
| 54 |
101-995 |
5.5" Wheel
|
USD$14.27
|
|
|
101-995 |
| 55 |
101-996 |
Hub Cap (grey)
|
USD$2.44
|
|
|
101-996 |
| 56 |
101-997 |
Handle Guide
|
USD$7.44
|
|
|
101-997 |
| 57 |
900-155 |
Hose Clamp 9.5mm
|
USD$2.25
|
|
|
900-155 |
| 58 |
101-998 |
Handle Assembly
|
USD$50.01
|
|
|
101-998 |
| 59 |
101-999 |
Fuel Strainer
|
USD$3.65
|
|
|
101-999 |
| 60 |
102-001 |
Fuel Filter
|
USD$8.96
|
|
|
102-001 |
| 61 |
102-002 |
Wiring Harness
|
USD$26.77
|
|
|
102-002 |
| 62 |
102-003 |
Ground Wire
|
USD$6.42
|
|
|
102-003 |
| 63 |
900-027 |
Serrated Lock Washer 6mm (Zn)
|
USD$2.04
|
|
|
900-027 |
| 64 |
102-165 |
Control Panel Assembly (eZV4500RVi)
|
USD$91.93
|
|
|
102-165 |
| 65 |
900-192 |
Bolt, Phillips Pan Head M4x16 (Zn)
|
USD$2.07
|
|
|
900-192 |
| 66 |
900-193 |
Flat Washer 21x6x1.96mm (Zn)
|
USD$2.15
|
|
|
900-193 |
| 67 |
900-194 |
Self-tapping Screw, Phillips Pan Head M4.2x9 (Zn)
|
USD$1.99
|
|
|
900-194 |
| 68 |
900-025 |
Nut, Serrated Flange M6 (Zn)
|
USD$1.99
|
|
|
900-025 |
| 69 |
900-264 |
Circlip 14mm (Zn)
|
USD$2.61
|
|
|
900-264 |
| 70 |
900-195 |
Nut, Hex M6 (Zn)
|
USD$1.99
|
|
|
900-195 |
| 71 |
102-006 |
Recoil Grip
|
USD$4.03
|
|
|
102-006 |
| 72 |
102-007 |
Recoil Grip Cap
|
USD$2.78
|
|
|
102-007 |
| 73 |
900-196 |
Bolt, Phillips Pan Head M5x12 (BLK)
|
USD$2.18
|
|
|
900-196 |
| 74 |
900-197 |
Bolt, Phillips Pan Head M6x16 (BLK)
|
USD$2.80
|
|
|
900-197 |
| 75 |
900-198 |
Locking Bolt, Phillips Pan Head, M6x12 (BLK)
|
USD$2.70
|
|
|
900-198 |
| 76 |
900-199 |
Square Nut M6 (Zn)
|
USD$2.30
|
|
|
900-199 |
| 77 |
102-008 |
Fuel Shutoff Valve
|
USD$8.36
|
|
|
102-008 |
| 78 |
102-009 |
Front Cover, fuel shutoff valve
|
USD$4.50
|
|
|
102-009 |
| 79 |
102-010 |
Rear Cover, fuel shutoff valve
|
USD$4.30
|
|
|
102-010 |
| 80 |
102-011 |
Wire Reel
|
USD$5.25
|
|
|
102-011 |
| 81 |
102-012 |
Bracket, fuel shutoff valve
|
USD$4.37
|
|
|
102-012 |
| 82 |
102-013 |
Inverter (4.5kW)
|
USD$182.18
|
|
|
102-013 |
| 83 |
900-036 |
Hose Clamp 10mm
|
USD$2.51
|
|
|
900-036 |
| 84 |
900-081 |
Nut, Serrated Flange M8 (Zn)
|
USD$2.18
|
|
|
900-081 |
| 85 |
900-115 |
Flat Washer 4mm (Zn)
|
USD$3.55
|
|
|
900-115 |
| 86 |
102-015 |
Rubber Oil Plug
|
USD$3.69
|
|
|
102-015 |
| 87 |
900-200 |
Self-tapping Screw, Phillips Pan Head M4.2x13 (Zn)
|
USD$1.99
|
|
|
900-200 |
| 88 |
900-201 |
Bolt, Flange M6x8 (Zn)
|
USD$2.04
|
|
|
900-201 |
| 89 |
900-004 |
21mm-thread Bolt, Flange M6x30 (Zn)
|
USD$2.18
|
|
|
900-004 |
| 90 |
900-057 |
Bolt, Flange M5x12 (Zn)
|
USD$2.07
|
|
|
900-057 |
| 91 |
900-134 |
Bolt, Flange M6x20 (BLK)
|
USD$2.15
|
|
|
900-134 |
| 92 |
900-085 |
Bolt, Flange M6x16 (Zn)
|
USD$2.07
|
|
|
900-085 |
| 93 |
900-001 |
Bolt, Flange M6x12 (Zn)
|
USD$2.08
|
|
|
900-001 |
| 94 |
102-016 |
Fuel Hose (Canister & Fuel Tank)
|
USD$4.50
|
|
|
102-016 |
| 95 |
102-017 |
Canister
|
USD$18.77
|
|
|
102-017 |
| 96 |
102-018 |
Fuel Hose (Canister & Air Filter)
|
USD$3.61
|
|
|
102-018 |
| 97 |
101-236 |
Duplex Receptacle L5-20R
|
USD$7.44
|
|
|
101-236 |
| 98 |
101-664 |
Duplex Receptacle Cover L5-20/GFCI
|
USD$4.77
|
|
|
101-664 |
| 99 |
102-020 |
Starting Indicator Light
|
USD$8.83
|
|
|
102-020 |
| 100 |
101-424 |
3-hole RV Receptacle TT-30R
|
USD$15.57
|
|
|
101-424 |
| 101 |
101-856 |
Receptacle Cover TT-30/L14-50R
|
USD$6.24
|
|
|
101-856 |
| 102 |
102-022 |
Hour Meter
|
USD$22.44
|
|
|
102-022 |
| 103 |
102-023 |
Electric Start Button
|
USD$15.18
|
|
|
102-023 |
| 104 |
101-671 |
ECO Switch 12A
|
USD$4.50
|
|
|
101-671 |
| 105 |
101-672 |
12A ECO Switch Cover
|
USD$6.24
|
|
|
101-672 |
| 106 |
102-024 |
Battery Chager Receptacle
|
USD$7.36
|
|
|
102-024 |
| 107 |
101-662 |
Indicator Light
|
USD$9.53
|
|
|
101-662 |
| 108 |
102-025 |
ON/OFF Switch 16A (Red)
|
USD$4.98
|
|
|
102-025 |
| 109 |
101-673 |
DC 12V Receptacle
|
USD$11.88
|
|
|
101-673 |
| 110 |
101-665 |
Reset Button Switch 8A
|
USD$10.31
|
|
|
101-665 |
| 111 |
101-667 |
Parallel Port
|
USD$7.94
|
|
|
101-667 |
| 112 |
101-668 |
Parallel Port Cover
|
USD$6.24
|
|
|
101-668 |
| 113 |
101-675 |
Ground Terminal
|
USD$3.69
|
|
|
101-675 |
| 114 |
102-027 |
USB Port (2.1A)
|
USD$13.39
|
|
|
102-027 |
| 115 |
102-028 |
USB Dust Cover
|
USD$3.41
|
|
|
102-028 |
| 116 |
101-396 |
Reset Button Switch 20A (L-Type)
|
USD$10.14
|
|
|
101-396 |
| 117 |
101-425 |
Reset Button Switch 30A (L-Type)
|
USD$8.49
|
|
|
101-425 |
| 118 |
101-857 |
Reset Button Switch Cover
|
USD$5.33
|
|
|
101-857 |
| 119 |
103-119 |
Remote
|
USD$18.47
|
|
|
103-119 |
| 120 |
102-217 |
12.6V/0.8Ah Wall Charger
|
USD$16.59
|
|
|
102-217 |
|
101-001 |
DC Battery Charging Cable
|
USD$15.87
|
|
|
101-001 |
|
101-827 |
Spark Plug Wrench (22x180mm)
|
USD$5.73
|
|
|
101-827 |
|
102-292 |
Funnel
|
USD$4.56
|
|
|
102-292 |
|
900-249 |
English Manual (eZV4500i, eZV4500RVi)
|
USD$6.92
|
|
|
900-249 |
|
900-250 |
French Manual (eZV4500i, eZV4500RVi)
|
USD$6.92
|
|
|
900-250 |
