| 1 |
101-031 |
Base
|
USD$44.46
|
|
|
101-031 |
| 2, 4, 11, 27, 30 |
900-001 |
Bolt, Flange M6x12 (Zn)
|
USD$2.08
|
|
|
900-001 |
| 3 |
101-034 |
Rubber foot
|
USD$4.37
|
|
|
101-034 |
| 5 |
101-036 |
Anti Vibration Motor Mount
|
USD$6.88
|
|
|
101-036 |
| 6 |
900-088 |
Lock Nut, Flange M6 (Zn)
|
USD$2.07
|
|
|
900-088 |
| 7 |
101-035 |
Anti Vibration Rubber Mount, Engine
|
USD$3.76
|
|
|
101-035 |
| 8 |
101-037 |
Anti Vibration Rubber Mount, Motor
|
USD$3.55
|
|
|
101-037 |
| 9 |
101-506 |
Fuel Shutoff Valve
|
USD$7.16
|
|
|
101-506 |
| 10 |
101-002 |
Complete Engine Assembly (80cc)
|
USD$308.96
|
|
|
101-002 |
| 12 |
101-008 |
Motor Cover (rear)
|
USD$35.85
|
|
|
101-008 |
| 13 |
900-055 |
Dowel Pin 8x12mm
|
USD$2.04
|
|
|
900-055 |
| 14, 18, 25 |
900-004 |
21mm-thread Bolt, Flange M6x30 (Zn)
|
USD$2.18
|
|
|
900-004 |
| 15 |
101-011 |
Rubber Plug
|
USD$2.87
|
|
|
101-011 |
| 16 |
101-009 |
Wire Bracket
|
USD$6.64
|
|
|
101-009 |
| 17 |
101-006 |
Stator
|
USD$101.87
|
|
|
101-006 |
| 19 |
101-003 |
Rotor
|
USD$74.96
|
|
|
101-003 |
| 20 |
900-208 |
Nut, Serrated Flange M12 (Zn)
|
USD$2.54
|
|
|
900-208 |
| 21 |
900-051 |
Flat Washer 18x12x1mm (Zn)
|
USD$2.07
|
|
|
900-051 |
| 22, 39 |
900-022 |
Self-tapping Screw, Phillips Pan Head M4.8x16 (BLK)
|
USD$2.18
|
|
|
900-022 |
| 23 |
900-027 |
Serrated Lock Washer 6mm (Zn)
|
USD$2.04
|
|
|
900-027 |
| 24 |
900-578 |
Bolt with washers, Phillips Hex Head M6x14 (Zn)
|
USD$2.74
|
|
|
900-578 |
| 26 |
101-025 |
Inverter
|
USD$167.39
|
|
|
101-025 |
| 28 |
900-026 |
Bolt, Phillips Pan Head M4x12 (BLK)
|
USD$1.99
|
|
|
900-026 |
| 29 |
101-020 |
Inverter Bracket
|
USD$10.56
|
|
|
101-020 |
| 31, 89 |
101-023 |
Rubber Plug, Fuel Tank
|
USD$2.61
|
|
|
101-023 |
| 32 |
101-022 |
Rubber Grommet, Inverter Bracket
|
USD$2.61
|
|
|
101-022 |
| 33 |
101-028 |
Inverter Cover
|
USD$6.86
|
|
|
101-028 |
| 36 |
900-657 |
Bolt, Phillips Pan Head M5x12 (Zn)
|
USD$2.07
|
|
|
900-657 |
| 37 |
101-026 |
Rectifier Diode
|
USD$8.63
|
|
|
101-026 |
| 38 |
900-618 |
Bolt with washers, Phillips Pan Head M5x20 (Zn)
|
USD$2.04
|
|
|
900-618 |
| 40, 12-45 |
101-090 |
Air Filter Maintenance Cover (9u)
|
USD$15.99
|
|
|
101-090 |
| 41, 104 |
900-018 |
Locking Bolt, Phillips Pan Head M5x16 (BLK)
|
USD$1.99
|
|
|
900-018 |
| 47, 70-74 |
101-049 |
Maintenance Cover (Left, Grey)
|
USD$37.14
|
|
|
101-049 |
| 48 |
103-699 |
Control Panel Housing
|
USD$16.69
|
|
|
103-699 |
| 49, 56 |
101-051 |
Rubber Seal Set
|
USD$2.15
|
|
|
101-051 |
| 50 |
900-656 |
Bolt, Phillips Pan Head M5x10 (Zn)
|
USD$1.99
|
|
|
900-656 |
| 55 |
101-112 |
Choke Lever (Manual)
|
USD$9.48
|
|
|
101-112 |
| 57 |
103-704 |
Cover Frame, Rope Guide
|
USD$6.81
|
|
|
103-704 |
| 58 |
101-007 |
Indicator Light
|
USD$14.05
|
|
|
101-007 |
| 59 |
900-014 |
Bolt with washers, Phillips Pan Head M5x16 (Zn)
|
USD$2.55
|
|
|
900-014 |
| 60 |
900-754 |
Flat Washer 5mm (Zn)
|
USD$1.99
|
|
|
900-754 |
| 61, 87 |
101-059 |
Rubber Bumper
|
USD$3.11
|
|
|
101-059 |
| 62 |
101-055 |
Handle Grip
|
USD$3.11
|
|
|
101-055 |
| 63 |
101-197 |
Recoil Grip Cap
|
USD$2.61
|
|
|
101-197 |
| 64 |
900-314 |
Self-tapping Screw, Phillips Pan Head M2.9X10 (BLK)
|
USD$1.99
|
|
|
900-314 |
| 65 |
101-194 |
Rope Guide, Recoil Statrer
|
USD$5.60
|
|
|
101-194 |
| 66 |
101-195 |
Rivet 3x10mm
|
USD$1.95
|
|
|
101-195 |
| 68, 75, 88 |
900-209 |
Spring Nut ST4.8x17mm (Zn)
|
USD$2.95
|
|
|
900-209 |
| 69, 85, 91 |
900-583 |
Bolt, Flange M6x12 (BLK)
|
USD$2.18
|
|
|
900-583 |
| 76 |
101-012 |
Fuel Tank
|
USD$52.29
|
|
|
101-012 |
| 77 |
101-017 |
Fuel Cap
|
USD$11.31
|
|
|
101-017 |
| 78 |
101-015 |
Fuel Strainer
|
USD$4.56
|
|
|
101-015 |
| 79 |
101-016 |
Fuel Deflector
|
USD$10.65
|
|
|
101-016 |
| 80 |
101-071 |
Fuel Shutoff Knob
|
USD$2.61
|
|
|
101-071 |
| 81 |
900-192 |
Bolt, Phillips Pan Head M4x16 (Zn)
|
USD$2.07
|
|
|
900-192 |
| 82 |
101-018 |
Rubber Cover, Fuel Tank
|
USD$2.54
|
|
|
101-018 |
| 83 |
900-295 |
Hose Clamp 8.5mm
|
USD$2.35
|
|
|
900-295 |
| 84 |
101-013 |
Fuel Hose (Fuel Shutoff Valve to Carburetor)
|
USD$2.44
|
|
|
101-013 |
| 86, 93-100 |
101-083 |
Maintenance Cover (Right, Grey)
|
USD$36.48
|
|
|
101-083 |
| 90 |
101-146 |
Seal Plug
|
USD$2.35
|
|
|
101-146 |
| 92, 101,105, 109 |
900-038 |
Bolt, Phillips Pan Head M5x20 (BLK)
|
USD$1.99
|
|
|
900-038 |
| 102-103 |
101-087 |
Spark Plug Cover
|
USD$1.99
|
|
|
101-087 |
| 106 |
101-040 |
Rear Cover
|
USD$5.01
|
|
|
101-040 |
| 107 |
101-039 |
Air Director (Rubber）
|
USD$15.59
|
|
|
101-039 |
| 110 |
900-575 |
Internal Serrated Curved Washer 14x5mm (BLK)
|
USD$2.15
|
|
|
900-575 |
| 111 |
101-092 |
Control Panel Assembly (eZV2000S)
|
USD$84.48
|
|
|
101-092 |
| 112 |
101-298 |
Control Panel Plate
|
USD$19.94
|
|
|
101-298 |
| 113 |
900-021 |
Bolt, Phillips Pan Head M5x16 (BLK)
|
USD$2.07
|
|
|
900-021 |
| 114 |
900-032 |
Serrated Lock Washer 5mm (Zn)
|
USD$2.17
|
|
|
900-032 |
| 115 |
900-030 |
Flat Washer 10x5x0.96mm (Zn)
|
USD$3.55
|
|
|
900-030 |
| 116 |
900-019 |
Spring Washer 5mm (Zn)
|
USD$2.33
|
|
|
900-019 |
| 117 |
900-033 |
Nut, Hex M5 (BLK)
|
USD$1.99
|
|
|
900-033 |
| 118 |
900-008 |
Serrated Lock Washer 4mm
|
USD$2.17
|
|
|
900-008 |
| 119 |
900-007 |
Bolt, Phillips Pan Head M4x10 (Zn)
|
USD$1.99
|
|
|
900-007 |
| 120 |
101-066 |
Switch Cover
|
USD$4.36
|
|
|
101-066 |
| 121 |
101-128 |
ECO Switch 12A
|
USD$5.34
|
|
|
101-128 |
| 122 |
101-357 |
Duplex USB Port
|
USD$23.58
|
|
|
101-357 |
| 123 |
101-189 |
Reset Switch
|
USD$7.16
|
|
|
101-189 |
| 124 |
101-541 |
DC 12V Receptacle Cover
|
USD$4.25
|
|
|
101-541 |
| 125 |
101-673 |
DC 12V Receptacle
|
USD$11.88
|
|
|
101-673 |
| 126 |
101-043 |
Reset Button Switch 6A (L-Type)
|
USD$10.40
|
|
|
101-043 |
| 127 |
101-396 |
Reset Button Switch 20A (L-Type)
|
USD$10.14
|
|
|
101-396 |
| 128 |
900-039 |
Nut, Hex M4 (Zn)
|
USD$2.47
|
|
|
900-039 |
| 129 |
900-042 |
Bolt, Phillips Flat Head M4x10 (BLK)
|
USD$1.99
|
|
|
900-042 |
| 130 |
101-236 |
Duplex Receptacle L5-20R
|
USD$7.44
|
|
|
101-236 |
| 131 |
101-664 |
Duplex Receptacle Cover L5-20/GFCI
|
USD$4.77
|
|
|
101-664 |
