| 1 |
101-117 |
Base
|
USD$44.46
|
|
|
101-117 |
| 2 |
101-034 |
Rubber foot
|
USD$4.37
|
|
|
101-034 |
| 3, 11, 86 |
900-001 |
Bolt, Flange M6x12 (Zn)
|
USD$2.08
|
|
|
900-001 |
| 4 |
101-036 |
Anti Vibration Motor Mount
|
USD$6.88
|
|
|
101-036 |
| 5 |
900-088 |
Lock Nut, Flange M6 (Zn)
|
USD$2.07
|
|
|
900-088 |
| 6 |
101-035 |
Anti Vibration Rubber Mount, Engine
|
USD$3.76
|
|
|
101-035 |
| 7 |
101-037 |
Anti Vibration Rubber Mount, Motor
|
USD$3.55
|
|
|
101-037 |
| 8 |
900-199 |
Square Nut M6 (Zn)
|
USD$2.30
|
|
|
900-199 |
| 9 |
900-209 |
Spring Nut ST4.8x17mm (Zn)
|
USD$2.95
|
|
|
900-209 |
| 10 |
101-002 |
Complete Engine Assembly (80cc)
|
USD$308.96
|
|
|
101-002 |
| 12 |
101-008 |
Motor Cover (rear)
|
USD$35.85
|
|
|
101-008 |
| 13 |
900-055 |
Dowel Pin 8x12mm
|
USD$2.04
|
|
|
900-055 |
| 14 |
900-004 |
21mm-thread Bolt, Flange M6x30 (Zn)
|
USD$2.18
|
|
|
900-004 |
| 15 |
101-011 |
Rubber Plug
|
USD$2.87
|
|
|
101-011 |
| 16 |
101-009 |
Wire Bracket
|
USD$6.64
|
|
|
101-009 |
| 17 |
101-006 |
Stator
|
USD$101.87
|
|
|
101-006 |
| 18 |
101-003 |
Rotor
|
USD$74.96
|
|
|
101-003 |
| 19 |
900-208 |
Nut, Serrated Flange M12 (Zn)
|
USD$2.54
|
|
|
900-208 |
| 20 |
900-051 |
Flat Washer 18x12x1mm (Zn)
|
USD$2.07
|
|
|
900-051 |
| 21 |
900-022 |
Self-tapping Screw, Phillips Pan Head M4.8x16 (BLK)
|
USD$2.18
|
|
|
900-022 |
| 22 |
101-106 |
Inverter
|
USD$183.95
|
|
|
101-106 |
| 23 |
101-109 |
Rubber Cover (Bottom)
|
USD$1.99
|
|
|
101-109 |
| 24 |
101-107 |
Rubber Cover (Side)
|
USD$1.99
|
|
|
101-107 |
| 25 |
101-026 |
Rectifier Diode
|
USD$8.63
|
|
|
101-026 |
| 26 |
900-026 |
Bolt, Phillips Pan Head M4x12 (BLK)
|
USD$1.99
|
|
|
900-026 |
| 27 |
900-618 |
Bolt with washers, Phillips Pan Head M5x20 (Zn)
|
USD$2.04
|
|
|
900-618 |
| 28, 39-43 |
101-111 |
Maintenance Cover (Left, Grey)
|
USD$24.56
|
|
|
101-111 |
| 29 |
900-005 |
Shoulder Bolt, Flange M6x9 (BLK)
|
USD$2.39
|
|
|
900-005 |
| 30 |
101-112 |
Choke Lever (Manual)
|
USD$9.48
|
|
|
101-112 |
| 31 |
101-055 |
Handle Grip
|
USD$3.11
|
|
|
101-055 |
| 32 |
101-197 |
Recoil Grip Cap
|
USD$2.61
|
|
|
101-197 |
| 33 |
900-314 |
Self-tapping Screw, Phillips Pan Head M2.9X10 (BLK)
|
USD$1.99
|
|
|
900-314 |
| 34 |
101-059 |
Rubber Bumper
|
USD$3.11
|
|
|
101-059 |
| 35 |
101-194 |
Rope Guide, Recoil Statrer
|
USD$5.60
|
|
|
101-194 |
| 37 |
101-195 |
Rivet 3x10mm
|
USD$1.95
|
|
|
101-195 |
| 38 |
101-196 |
Ring Cover
|
USD$8.62
|
|
|
101-196 |
| 44 |
101-017 |
Fuel Cap
|
USD$11.31
|
|
|
101-017 |
| 45 |
101-015 |
Fuel Strainer
|
USD$4.56
|
|
|
101-015 |
| 46 |
101-099 |
Fuel Deflector
|
USD$10.45
|
|
|
101-099 |
| 47 |
101-103 |
Fuel Shutoff Knob
|
USD$3.25
|
|
|
101-103 |
| 48 |
101-018 |
Rubber Cover, Fuel Tank
|
USD$2.54
|
|
|
101-018 |
| 49 |
101-102 |
Fuel Hose (Fuel Shutoff Valve to Carburetor)
|
USD$13.98
|
|
|
101-102 |
| 50 |
900-179 |
Hose Clamp 9mm
|
USD$2.44
|
|
|
900-179 |
| 51 |
900-582 |
Bolt, Phillips Pan Head M4x16 (BLK)
|
USD$1.99
|
|
|
900-582 |
| 52, 57-68 |
101-114 |
Casing (right, grey)
|
USD$17.76
|
|
|
101-114 |
| 53 |
101-023 |
Rubber Plug, Fuel Tank
|
USD$2.61
|
|
|
101-023 |
| 54 |
101-146 |
Seal Plug
|
USD$2.35
|
|
|
101-146 |
| 55, 81, 87 |
900-021 |
Bolt, Phillips Pan Head M5x16 (BLK)
|
USD$2.07
|
|
|
900-021 |
| 56 |
900-023 |
E-Clip 9mm
|
USD$2.61
|
|
|
900-023 |
| 69-74 |
101-116 |
Air Filter Maintenance Cover (2kW 9u)
|
USD$15.99
|
|
|
101-116 |
| 75 |
900-018 |
Locking Bolt, Phillips Pan Head M5x16 (BLK)
|
USD$1.99
|
|
|
900-018 |
| 76-77 |
101-115 |
Spark Plug Maintenance Cover (Light Grey)
|
USD$4.24
|
|
|
101-115 |
| 78, 83 |
101-118 |
Rear Cover
|
USD$22.83
|
|
|
101-118 |
| 79 |
101-119 |
Air Director (Rubber）
|
USD$21.46
|
|
|
101-119 |
| 80 |
103-691 |
Spong, Air Director
|
USD$3.69
|
|
|
103-691 |
| 82 |
900-575 |
Internal Serrated Curved Washer 14x5mm (BLK)
|
USD$2.15
|
|
|
900-575 |
| 84, 88-89 |
101-120 |
Casing (Front)
|
USD$18.66
|
|
|
101-120 |
| 85 |
101-051 |
Rubber Seal Set
|
USD$2.15
|
|
|
101-051 |
| 90 |
101-121 |
Control Panel Assembly (eZV2000P)
|
USD$84.48
|
|
|
101-121 |
| 91 |
900-196 |
Bolt, Phillips Pan Head M5x12 (BLK)
|
USD$2.18
|
|
|
900-196 |
| 92 |
900-029 |
Bolt, Phillips Pan Head M5x25 (BLK)
|
USD$1.99
|
|
|
900-029 |
| 93 |
900-032 |
Serrated Lock Washer 5mm (Zn)
|
USD$2.17
|
|
|
900-032 |
| 94 |
900-030 |
Flat Washer 10x5x0.96mm (Zn)
|
USD$3.55
|
|
|
900-030 |
| 95 |
900-019 |
Spring Washer 5mm (Zn)
|
USD$2.33
|
|
|
900-019 |
| 96 |
900-033 |
Nut, Hex M5 (BLK)
|
USD$1.99
|
|
|
900-033 |
| 97 |
101-128 |
ECO Switch 12A
|
USD$5.34
|
|
|
101-128 |
| 98 |
101-066 |
Switch Cover
|
USD$4.36
|
|
|
101-066 |
| 99 |
101-189 |
Reset Switch
|
USD$7.16
|
|
|
101-189 |
| 100 |
101-398 |
Parallel Port
|
USD$13.08
|
|
|
101-398 |
| 101 |
101-098 |
Fuel Tank
|
USD$54.24
|
|
|
101-098 |
| 102 |
101-506 |
Fuel Shutoff Valve
|
USD$7.16
|
|
|
101-506 |
| 103 |
101-673 |
DC 12V Receptacle
|
USD$11.88
|
|
|
101-673 |
| 104 |
101-541 |
DC 12V Receptacle Cover
|
USD$4.25
|
|
|
101-541 |
| 105 |
101-043 |
Reset Button Switch 6A (L-Type)
|
USD$10.40
|
|
|
101-043 |
| 106 |
101-007 |
Indicator Light
|
USD$14.05
|
|
|
101-007 |
| 107 |
900-014 |
Bolt with washers, Phillips Pan Head M5x16 (Zn)
|
USD$2.55
|
|
|
900-014 |
| 108 |
101-044 |
Reset Button Switch 15A (L-Type)
|
USD$10.75
|
|
|
101-044 |
| 109 |
101-236 |
Duplex Receptacle L5-20R
|
USD$7.44
|
|
|
101-236 |
| 110 |
101-664 |
Duplex Receptacle Cover L5-20/GFCI
|
USD$4.77
|
|
|
101-664 |
| 111 |
900-042 |
Bolt, Phillips Flat Head M4x10 (BLK)
|
USD$1.99
|
|
|
900-042 |
| 112 |
900-039 |
Nut, Hex M4 (Zn)
|
USD$2.47
|
|
|
900-039 |
| 113 |
900-007 |
Bolt, Phillips Pan Head M4x10 (Zn)
|
USD$1.99
|
|
|
900-007 |
| 114 |
900-008 |
Serrated Lock Washer 4mm
|
USD$2.17
|
|
|
900-008 |
